IS 118MM/4NO-8E0,50129856 Leuze Inductive Proximity Sensor
Specifications:-
Basic Data:-
| Series | 118 |
| Typ. operating range limit Sn | 8 mm |
| Operating range Sa | 0 … 6.5 mm |
Electrical Data:-
| Protective circuit | Overload protection Polarity reversal protection Short circuit protected |
Performance Data:-
| Supply voltage UB | 10 … 30 V, DC |
| Residual ripple | 10 %, From UB |
| Open-circuit current | 0 … 10 mA |
| Temperature drift, max. (in % of Sr) | 10 % |
| Repeatability, max. (in % of Sr) | 1 % |
| Switching hysteresis | 15 % |
Outputs:-
| Number of digital switching outputs | 1 Piece(s) |
Switching Outputs:-
| Voltage type | DC |
| Switching current, max. | 200 mA |
| Residual current, max. | 0.01 mA |
| Voltage drop | ≤ 2 V |
Switching Outputs 1:-
| Switching element | Transistor, PNP |
| Switching principle | NO (normally open) |
Time Behavior:-
| Switching frequency | 3,000 Hz |
Connection:-
| Number of connections | 1 Piece(s) |
Connection 1:-
| Function | Signal OUT Voltage supply |
| Type of connection | Cable |
| Cable length | 2,000 mm |
| Sheathing material | PVC |
| Cable color | Black |
| Number of conductors | 3 -wire |
| Wire cross section | 0.35 mm² |
Mechanical Data:-
| Design | Cylindrical |
| Thread size | M18 x 1 mm |
| Dimension (Ø x L) | 18 mm x 55 mm |
| Type of installation | Embedded |
| Housing material | Metal |
| Metal housing | Nickel-plated brass |
| Sensing face material | Plastic, Polybutylene (PBT) |
| Housing color | Red, RAL 3000 Silver |
| Type of fastening | Mounting thread |
| Standard measuring plate | 24 x 24 mm², Fe360 |
Operation & Display:-
| Type of display | LED |
| Number of LEDs | 1 Piece(s) |
Environmental Data:-
| Ambient temperature, operation | -25 … 70 °C |
| Ambient temperature, storage | -25 … 70 °C |
Data Sheet: Pdf
Other Model:-
IS 118MM/4NC-16N-M12 ; Part no.: 50129987
IS 118 MM/4NO-16N-M12 ; Part no.: 50129985
IS 118MM/2NC-16N-M12 ; Part no.: 50129984
IS 118 MM/2NO-16N-M12 ; Part no.: 50129983
IS 118 MM/4NC-8E0-M12 ; Part no.: 50129982
IS 118 MM/4NO-8E0-M12 ; Part no.: 50129981
IS 118 MM/2NC-8E0-M12 ; Part no.: 50129980
IS 118 MM/2NO-8E0-M12 ; Part no.: 50129979
IS 118MM/4NC-16N ; Part no.: 50129978
IS 118MM/4NO-16N ; Part no.: 50129977
IS 118MM/2NC-16N ; Part no.: 50129961
IS 118MM/2NO-16N ; Part no.: 50129960
IS 118 MM/4NC-8E0 ; Part no.: 50129857
IS 118 MM/4NO-8E0 ; Part no.: 50129856
IS 118 MM/2NC-8E0 ; Part no.: 50129854
IS 118 MM/2NO-8E0 ; Part no.: 50129843
