KRT21M-09.PL3/42-M12, 50127841 Leuze Contrast Sensor

In Stock
Highlights:
  • Operating range: 9 mm ± 3 mm.
  • Beam path: Focused.
  • Light source: LED, RGB.
  • Transmitted-signal shape: Pulsed.
  • Light spot size [at sensor distance]: 1.5 mm x 5 mm.
  • Light spot orientation: Vertical.
  • Type of light spot geometry: Rectangular.
Compare
Estimated Delivery: 1-3 Days
15 June - 17 June
Description

KRT21M-09.PL3/42-M12, 50127841 Leuze Contrast Sensor

Leuze Contrast Sensor

Contrast sensors detect and compare contrasts very precisely through the use of different light sources such as white light, laser-generated red light or RGB light. The detected contrasts marks are then reported to the process with minimal signal jitter. Through the automatic selection of the right transmitter colors, various color or gray value combinations can be reliably detected. Bar graph indicators offer additional ease in making adjustments during manual setup.

Technical features:-

Optical Data:-

Operating range 9 mm ± 3 mm
Beam path Focused
Light source LED, RGB
Transmitted-signal shape Pulsed
Light spot size [at sensor distance] 1.5 mm x 5 mm
Light spot orientation Vertical
Type of light spot geometry Rectangular
Light beam exit On face
Focus Fixed

Electrical Data:-

Protective circuit Polarity reversal protection
Short circuit protected

Perfomance Data:-

Supply voltage UB 10 … 30 V, DC
Residual ripple 0 … 15 %, From UB
Open-circuit current 0 … 25 mA

Outputs:-

  • Switching Outputs:-
Voltage type DC
Switching current, max. 100 mA
Switching voltage high: ≥(UB-2V)
low: ≤ 2 V
  • Switching Outputs 1:-
Switching element Transistor, PNP
Switching principle Switching signal on mark
  • Switching Outputs 2:-
Switching element Transistor, NPN
Switching principle Switching signal on mark

Mechanical Data:-

Design Cubic
Dimension (W x H x L) 31 mm x 53 mm x 80.1 mm
Housing material Plastic
Plastic housing ABS
Net weight 90 g
Housing color Black
Type of fastening Front mounting with thread
Through-hole mounting

Operations & Display:-

Type of display LED
Number of LEDs 3 Piece(s)
Operational controls Teach button
Function of the operational control Sensitivity adjustment

Environmental Data:-

Ambient temperature, operation -10 … 55 °C
Ambient temperature, storage -20 … 70 °C

Data Sheet  :-PDF
