HT5.1/2 , 50129399 Leuze Diffuse Sensor With Background Suppression
Standard models (LED and laser)
All-rounder for detecting and measuring: The new ODT 3C
In many industrial processes, it is not only important that an object is present, but also that it is in a specific position or on the conveyor belt at a specific distance from the machine. Even checking whether an object is separate or lying on top of another object on the conveyor belt can be crucial for the subsequent (packaging) process steps. To perform these tasks with a single sensor, the sensor must supply both switching and measuring information to the machine control. We have achieved this with the development of the new ODT 3C.
The ODT 3C is both a switching and a measuring sensor. This makes it ideal for applications that involve both detection and measurement tasks. As a result, our customers can now perform these tasks easily and effectively with a single sensor.
With the new ODT 3C.Available Stock In Bangladesh.
Technical features:-
Basic Data:-
| Series | 5 |
| Operating principle | Diffuse reflection principle with background suppression |
Special Version:-
Optical Data:-
| Black-white error | < 15% up to 200 mm |
| Operating range | Guaranteed operating range |
| Operating range, white 90% | 0.005 … 0.4 m |
| Operating range, gray 18% | 0.01 … 0.3 m |
| Operating range, black 6% | 0.015 … 0.2 m |
| Operating range limit | Typical operating range |
| Operating range limit | 0.005 … 0.4 m |
| Adjustment range | 15 … 400 mm |
| Beam path | Focused |
| Light source | LED, Red |
| Wavelength | 645 nm |
| LED group | Exempt group (in acc. with EN 62471) |
| Type of light spot geometry | Round |
| Focus | Fixed |
| Focal distance | 200 mm |
Electrical Data:-
| Protective circuit | Polarity reversal protection Short circuit protected |
Performance Data:-
| Supply voltage UB | 10 … 30 V, DC, Incl. residual ripple |
| Residual ripple | 0 … 15 %, From UB |
| Open-circuit current | 0 … 15 mA |
Outputs:-
| Number of digital switching outputs | 1 Piece(s) |
Switching Outputs 1:-
| Switching element | Transistor, NPN |
| Switching principle | Light switching |
Time Behavior:-
| Switching element | Transistor, NPN |
| Switching principle | Light switching |
Connection 1:-
| Function | Signal OUT Voltage supply |
| Type of connection | Cable |
| Cable length | 2,000 mm |
| Sheathing material | PUR |
| Cable color | Black |
| Number of conductors | 3 -wire |
| Wire cross section | 0.2 mm² |
Mechanical Data:-
| Dimension (W x H x L) | 11.4 mm x 32.1 mm x 17.8 mm |
| Housing material | Plastic |
| Plastic housing | PC-ABS |
| Lens cover material | Plastic / PMMA |
| Net weight | 50 g |
| Housing color | Black Red |
| Type of fastening | Two M3 threaded sleeves Via optional mounting device |
Operation & Display:-
| Type of display | LED |
| Operational controls | Multiturn potentiometer |
| Function of the operational control | Range adjustment |
Environmental Data:-
| Ambient temperature, operation | -40 … 60 °C |
| Ambient temperature, storage | -40 … 70 °C |
Data Sheet:-PDF
