IS 218MM/1NC.3-5E0, 50128152 Leuze Inductive Proximity Sensor

In Stock
Highlights:
  • DIA: 18MM
  • SN: 5MM
  • NO
  • SUPPLY VOLTAGE: 10-320 V
  • AC/DC
  • CABLE TYPE
  • 2 WIRE
  • METAL HOUSING
  • EMBEDDED



Compare
Estimated Delivery: 1-3 Days
15 October - 17 October
Description

IS 218MM/1NC.3-5E0,50128152 Leuze Inductive Proximity Sensor

Inductive Proximity Sensor

Specifications:-

Basic Data:-

Series 218
Typ. operating range limit Sn 5 mm
Operating range Sa 0 … 4 mm

Mesurement Data :-

Repeatability 0.5 mm

Electrical Data:-

Protective circuit Inductive protection
Polarity reversal protection
Short circuit protected

Performance Data:-

Supply voltage UB 10 … 320 V, AC/DC
Residual ripple 0 … 20 %, From UB
Open-circuit current 0 … 1 mA
Temperature drift, max. (in % of Sr) 10 %, Over the entire operating temperature range
Switching hysteresis 20 %

Outputs:-

Number of digital switching outputs 1 Piece(s)

Switching Outputs:-

Voltage type AC/DC
Switching current, max. 200 mA
Voltage drop ≤ 2 V

Switching Outputs 1:-

Switching element Relay, NO
Switching principle NO (normally open)

Time Behavior:-

Switching frequency 1,500 Hz
Oscillator frequency 175,000 Hz
Readiness delay 70 ms

Connection:-

Number of connections 1 Piece(s)

Connection 1:-

Function Voltage supply
Type of connection Cable
Cable length 2,000 mm
Sheathing material PVC
Cable color Black
Number of conductors 2 -wire
Wire cross section 0.34 mm²

Mechanical Data:-

Design Cylindrical
Thread size M18 x 1 mm
Dimension (Ø x L) 18 mm x 50 mm
Type of installation Embedded
Housing material Metal
Metal housing Chromed brass
Sensing face material Plastic, Polybutylene (PBT)
Net weight 116 g
Housing color Red, RAL 3000
Silver
Type of fastening Mounting thread
Via optional mounting device
Standard measuring plate 18 x 18 mm², Fe360

Operation & Display:-

Type of display LED
Number of LEDs 1 Piece(s)

Environmental Data:-

Ambient temperature, operation -25 … 70 °C
Ambient temperature, storage -25 … 70 °C

Data Sheet: Pdf

Other Model:-

IS 218MM/4NC-8E0-S12 ; Part no.: 50109702
IS 218MM/4NO-8E0-S12 ; Part no.: 50109701
IS 218MM/4NO-8E0 ; Part no.: 50109700
IS 218MM/2NO-8N0-S12 ; Part no.: 50109699
IS 218MM/2NO-8N0 ; Part no.: 50109698
IS 218MM/4NO-8N0-S12 ; Part no.: 50109697
IS 218MM/4NO-8N0 ; Part no.: 50109696
IS 218MM/2NO-5E0 ; Part no.: 50109694
IS 218MM/4NO-5E0-S12 ; Part no.: 50109693
IS 218MM/4NO-5E0 ; Part no.: 50109692
IS 218FM/4NC.5-5E0 ; Part no.: 50138121
IS 218FM/2NO.5-5E0 ; Part no.: 50128172
IS 218FM/2NO.5-5E0-S12 ; Part no.: 50128171
IS 218FM/4NO.5-5E0 ; Part no.: 50128170
IS 218FM/4NO.5-5E0-S12 ; Part no.: 50128169
IS 218FM/4NO.5F-20N-S12 ; Part no.: 50109734
IS 218FM/4NO.5F-10E-S12 ; Part no.: 50109732
IS 218MM/1NO.3-5E0 ; Part no.: 50128152
IS 218MM/1NC.3-5E0 ; Part no.: 50128151
