Leuze Capacitive Sensor LCS-2M30P-F20PNC-K020V , 50136562
Polarized Retro-Reflective Photoelectric Sensor
Capacitive sensors can detect solid, liquid or granular objects. With these sensors highly structured and non-dimensionally stable objects e.g. the fill levels of liquids or bulk materials can also be detected in direct contact with the medium or through a non-metallic container wall. They are also suitable for completeness inspections. Capacitive sensors also function reliably in an extremely dusty or dirty environment. An array of different designs and large operating ranges enable the use in practically all areas of application in industrial automation.
Technical features:-
Electrical Data:-
| Protective circuit | Polarity reversal protection Short circuit protected |
Performance Data:-
| Supply voltage UB | 10 … 30 V, DC |
| Residual ripple | 0 … 10 % |
| Open-circuit current | 10 mA |
| Temperature drift, max. (in % of Sr) | 10 % |
| Repeatability, max. (in % of Sr) | 5 % |
| Rated operating current | 200 mA |
Outputs:-
| Number of digital switching outputs | 1 Piece(s) |
Switching Outputs:-
| Type | Digital switching output |
| Voltage type | DC |
Switching Outputs 1:-
| Switching element | Transistor, PNP |
| Switching principle | NC (normally closed) |
Time Behavior:-
| Switching frequency | 100 Hz |
Connection:-
| Number of connections | 1 Piece(s) |
Connection 1:-
| Function | Signal OUT Voltage supply |
| Type of connection | Cable |
| Cable length | 2,000 mm |
| Sheathing material | PVC |
| Number of conductors | 3 -wire |
| Wire cross section | 0.35 mm² |
Mechanical Data:-
| Design | Cylindrical |
| Thread size | M30 x 1.5 mm |
| Dimension (Ø x L) | 30 mm x 85 mm |
| Type of installation | Embedded |
| Housing material | Plastic |
| Plastic housing | Polybutylene (PBT) |
| Sensing face material | Plastic, Polybutylene (PBT) |
| Cover material | Plastic, Polybutylene (PBT) |
Operation & Display:-
| Type of display | LED |
| Number of LEDs | 1 Piece(s) |
| Operational controls | Multiturn potentiometer |
| Function of the operational control | Sensitivity adjustment |
| Switching distance, adjustable | Yes |
Environmental Data:-
| Ambient temperature, operation | -25 … 70 °C |
Model :-
LCS-2M30P-N30NNC-K020V,LCS-2M30P-N30NNO-K020V,LCS-2M30P-N30PNC-K020V,LCS-2M30P-N30PNO-K020V,LCS-2M30P-N30NNC-M12,LCS-2M30P-N30NNO-M12,LCS-2M30P-N30PNC-M12,LCS-2M30P-N30PNO-M12,LCS-2M30B-N30NNC-K020V,LCS-2M30B-N30NNO-K020V,LCS-2M30B-N30PNC-K020V,LCS-2M30B-N30PNO-K020V,LCS-2M30B-N30NNC-M12,LCS-2M30B-N30NNO-M12,LCS-2M30B-N30PNO-M12,LCS-2M18P-N15NNC-K020V,LCS-2M18P-N15NNO-K020V,LCS-2M18P-N15PNC-K020V,LCS-2M18P-N15PNO-K020V,LCS-2M18P-N15NNC-M12,LCS-2M18P-N15NNO-M12,LCS-2M18P-N15PNC-M12
