GSU12/6GX.3-M12 , 50142879 Leuze Ultrasonic Fork Sensor

In Stock
Highlights:
  • Label width, min. : 4 mm
  • Label gap, min. : 2 mm
  • Medium: Transparent and not transparent
  • Number of digital switching outputs: 2
  • Switching element: Transistor
  • Push-pull
  • Switching principle: PNP light switching (switching in the gap),
Compare
Estimated Delivery: 1-3 Days
15 June - 17 June
Description

GSU12/6GX.3-M12 , 50142879 Leuze Ultrasonic Fork Sensor

Leuze Ultrasonic Fork Sensor

Fork sensors have a high level of operational reliability since they integrate the transmitter and receiver into a single unit. They are distinguished by their great sensitivity and easy mounting that doesn’t require alignment. The fork sensors are employed in the detection of print markings and small parts, including those on transparent films. Available Stock In Bangladesh.

Technical features:-

Electrical Data:

  • Protective circuit :-Polarity reversal protection.
    Short circuit protected.

Performance Data:–

Supply voltage UB
12 … 30 V, DC
Residual ripple 0 … 10 %, From UB
Open-circuit current 0 … 60 mA, Typical value

Outputs:-

Type
Digital switching output
Voltage type DC
Switching current, max. 100 mA
Switching voltage
high: ≥(UB-2V)
low: ≤ 2 V
Load capacity
0.01 µF

Switching Outputs 1:-

Switching element
Transistor, Push-pull
Switching principle PNP light switching (switching in the gap), NPN dark switching (switching on the label)

Switching Outputs 2:-

Switching element
Transistor, Push-pull
Switching principle NPN light switching (switching in the gap), PNP dark switching (switching on the label)

Mechanical Data:-

Design Fork
Mouth width 4 mm
Mouth depth 80 mm
Dimension (W x H x L) 22 mm x 46.9 mm x 96 mm
Housing material Metal
Metal housing Diecast zinc, with powder coating
Net weight 270 g
Housing color Red
Type of fastening Mounting thread
Through-hole mounting

Environmental Data:-

Ambient temperature, operation 0 … 60 °C
Ambient temperature, storage -40 … 70 °C

Data Sheet: PDF
