IPRK 18/A L.46 , 50040278 Leuze Polarized Retro-Reflective Photoelectric Sensor
Polarized Retro-Reflective Photoelectric Sensor
Technical features:-
Basic Data:-
| Series | 18 |
| Operating principle | Reflection principle |
| Application | Detection of highly transparent bottles Detection of highly transparent films and glass panes |
Special Version:-
| Special version | Autocollimation Tracking function Warning output |
Optical Data:-
| Operating range | 0 … 2.4 m |
| Operating range | Guaranteed operating range |
| Operating range limit | Typical operating range |
| Operating range limit | 0 … 3 m |
| Light source | LED, Red |
| Wavelength | 660 nm |
| LED group | 1 |
| Type of light spot geometry | Round |
Electrical Data:-
| Protective circuit | Polarity reversal protection Short circuit protected |
Performance Data:-
| Supply voltage UB | 26.5 … 31.6 V |
| Open-circuit current | 0 … 35 mA |
Time Behavior:-
| Switching frequency | 1,000 Hz |
| Response time | 0.5 ms |
| Readiness delay | 300 ms |
Interface:-
| Type | AS-Interface IO |
Connection:-
- Connection 1:-
| Function | AS-i interface Voltage supply |
| Type of connection | Connector |
| Thread size | M12 |
| Type | Male |
| Material | Stainless steel |
| No. of pins | 5 -pin |
| Encoding | A-coded |
Mechanical Data:-
| Dimension (W x H x L) | 15 mm x 50 mm x 33 mm |
| Housing material | Metal |
| Metal housing | Zinc |
| Lens cover material | Glass |
| Net weight | 75 g |
| Housing color | Red |
| Type of fastening | Mounting thread Through-hole mounting |
Operation & Display:-
| Type of display | LED |
| Operational controls | Step switch |
Environmental Data:-
| Ambient temperature, operation | -25 … 55 °C |
| Ambient temperature, storage | -40 … 70 °C |
Model:-
PRK5B/4X-2000-M8,PRK5B/PX-2000-M8 ,PRK55C.A3/LG-5000 ,SET PRK5B/4+TKS 40×60.A ,PRK5B.D/4X-200-M8 ,PRK53CL1.A3/LT-M8 ,SET PRK5B/4X-200-M12+BTU200MVKT,PRK53CL1.XA3/LG-M8 ,PRK5B.D/4X-200-M12 ,PRK5.M3/4P-200-M8 ,PRK5B.M1/4X-200-M12, PRK5B.M1/PX-M8,PRK5B/P-M8.3,PRK5B/4X-1000-M8 ,PRK5B.D/PX-200-M12 ,PRK5B.M1/PX-200-M12 ,PRK5B/4X-600-M8,PRK5B/NX-200-M12,PRK5B/PX-200-M12,PRK5B/NX-M8,PRK5B/PX-M8 ,PRK5B.M1/2 ,PRK5B.M1/2X-M8,PRK5B.M1/4,PRK5B.M1/4X-M8,PRK55CL1.A3/LG-200-M12,PRK55CL1.A3/LG-M8,PRK55C.A3/LG-200-M12 ,PRK55C.A3/LG-M8,PRK55C/LG-200-M12.
Data Sheet:- Pdf
Available Stock In Bangladesh
