PRK5B/4, 50145245 Leuze Photoelectric Sensor
Polarized Retro-Reflective Photoelectric Sensor
Photoelectric Sensor Price
Specifications:-
Basic Data:-
| Series | 5B |
| Operating principle | Reflection principle |
Optical Data:-
| Operating range | 0.02 … 5 m, With reflector TK(S) 100×100 |
| Operating range | Guaranteed operating range |
| Operating range limit | Typical operating range |
| Operating range limit | 0.02 … 6.5 m, With reflector TK(S) 100×100 |
| Light source | LED, Red |
| Wavelength | 645 nm |
| LED group | Exempt group (in acc. with EN 62471) |
Electrical Data:-
| Protective circuit | Polarity reversal protection Short circuit protected |
Performance Data:-
| Supply voltage UB | 10 … 30 V, DC, Incl. residual ripple |
| Residual ripple | 0 … 15 %, From UB |
| Open-circuit current | 0 … 20 mA |
Outputs:-
| Number of digital switching outputs | 1 Piece(s) |
Switching Outputs 1:-
| Switching element | Transistor, PNP |
| Switching principle | Light switching (dark switching by reversing polarity of UB) |
Time Behavior:-
| Switching frequency | 500 Hz |
| Response time | 1 ms |
| Readiness delay | 300 ms |
Connection:-
Connection 1:-
| Function | Signal OUT Voltage supply |
| Type of connection | Cable |
| Cable length | 2,000 mm |
| Sheathing material | PVC |
| Cable color | Black |
| Number of conductors | 3 -wire |
| Wire cross section | 0.14 mm² |
Mechanical Data:-
| Dimension (W x H x L) | 11 mm x 32.4 mm x 20 mm |
| Housing material | Plastic |
| Plastic housing | PC-ABS |
| Lens cover material | Plastic |
| Net weight | 44 g |
| Housing color | Black Red |
| Type of fastening | Two M3 threaded sleeves Via optional mounting device |
| Compatibility of materials | ECOLAB |
Operation & Display:-
| Type of display | LED |
Environmental Data:-
| Ambient temperature, operation | -40 … 60 °C |
| Ambient temperature, storage | -40 … 70 °C |
Data Sheet: Pdf
