Leuze Inductive Proximity Sensor IS 108 MM/4NC-2E0 , 50129929

In Stock
Highlights:
  • Series 108
  • Typ. operating range limit Sn   2 mm
  • Operating range Sa   0 … 1.6 mm



Compare
Estimated Delivery: 1-3 Days
15 June - 17 June
Category: Tags: ,
Description

Inductive Proximity Sensor

Specifications:-

Basic Data:-

Series 108
Typ. operating range limit Sn 2 mm
Operating range Sa 0 … 1.6 mm

Electrical Data:-

Protective circuit Overload protection
Polarity reversal protection
Short circuit protected

Performance Data:-

Supply voltage UB 10 … 30 V, DC
Residual ripple 10 %, From UB
Open-circuit current 0 … 10 mA
Temperature drift, max. (in % of Sr) 10 %
Repeatability, max. (in % of Sr) 1 %
Switching hysteresis 15 %

Outputs:-

Number of digital switching outputs 1 Piece(s)

Switching Outputs:-

Voltage type DC
Switching current, max. 100 mA
Residual current, max. 0.01 mA
Voltage drop ≤ 2 V

Switching Outputs 1:-

Switching element Transistor, PNP
Switching principle NC (normally closed)

Time Behavior:-

Switching frequency 3,000 Hz

Connection:-

Number of connections 1 Piece(s)

Connection 1:-

Function Signal OUT
Voltage supply
Type of connection Cable
Cable length 2,000 mm
Sheathing material PVC
Cable color Black
Number of conductors 3 -wire
Wire cross section 0.18 mm²

Mechanical Data:-

Design Cylindrical
Thread size M8 x 1 mm
Dimension (Ø x L) 8 mm x 45 mm
Type of installation Embedded
Housing material Metal
Metal housing Nickel-plated brass
Sensing face material Plastic, Polyoxymethylene (POM)
Housing color Red, RAL 3000
Silver
Type of fastening Mounting thread
Standard measuring plate 8 x 8 mm², Fe360

Operation & Display:-

Type of display LED
Number of LEDs 1 Piece(s)

Environmental Data:-

Ambient temperature, operation -25 … 70 °C
Ambient temperature, storage -25 … 70 °C

MODEL:-ISS 118MM/4NC-8E0-M12 ,IS 130MM/4NO-25N-M12 ,IS 130MM/4NC-25N-M12 ,IS 130MM/2NO-25N-M12 ,IS 130MM/2NC-25N-M12 ,ISS 108MM/4NO-4N0-M12,ISS 108MM/2NO-4N0-M12 ,ISS 108MM/4NO-2E0-M12 ,ISS 108MM/2NO-2E0-M12 ,IS 108MM/4NO-2E0-1000,IS 130MM/4NC-16E-M12 IS 130MM/4NO-16E-M12 ,IS 130MM/2NO-16E-M12 ,ISS 130MM/4NO-16E ,ISS 130MM/2NO-16E ISS 130MM/4NO-16E-M12,ISS 130MM/4NO-16E-M12 ,ISS 130MM/2NO-16E-M12 ,IS 130MM/2NC-16E-M12 ,IS 130MM/4NC-16E ,IS 130MM/4NO-16E ,IS 130MM/2NC-16E ,IS 130MM/2NO-16E ,ISS 118MM/4NO-16N-M12 ,ISS 118MM/2NO-16N-M12 IS 122PP/4NC-5E0,IS 122PP/4NO-5E0,IS 122PP/2NC-5E0 ,IS 122PP/2NO-5E0 ,IS 112 MM/4NO-4E0 ,IS 112 MM/2NC-4E0 ,IS 112 MM/2NO-4E0,IS 108 MM/2NC-4N0-M12,IS 108 MM/2NO-4N0-M12 ,IS 108 MM/4NC-2E0-M12,IS 108 MM/4NO-2E0-M12 ,IS 108 MM/2NC-2E0-M12,IS 108 MM/2NO-2E0-M12,IS 118 MM/4NC-8E0,IS 118 MM/4NO-8E0,IS 118 MM/2NO-8E0 ,IS 112 MM/2NC-4E0 ,IS 112 MM/2NO-4E0 IS 108 MM/2NC-4N0-M12 ,IS 108 MM/2NO-4N0-M12 ,IS 108 MM/4NC-2E0-M12 ,IS 108 MM/4NO-2E0-M12,IS 108 MM/2NC-2E0-M12 ,IS 118 MM/4NC-8E0 ,IS 122PP/2NO-5E0,IS 122PP/2NC-5E0,IS 122PP/4NO-5E0,IS 122PP/4NC-5E0,
