LCS-2M30P-F20NNC-K020V, 50136564 Leuze Capacitive Sensor
Specifications:-
Basic Data:-
| Series | LCS-2 |
| Switching distance Sn | 2 … 20 mm |
| Assured switching distance | 16.2 mm |
Electrical Data:-
| Protective circuit | Polarity reversal protection Short circuit protected |
Performance Data:-
| Supply voltage UB | 10 … 30 V, DC |
| Residual ripple | 0 … 10 % |
| Open-circuit current | 10 mA |
| Temperature drift, max. (in % of Sr) | 10 % |
| Repeatability, max. (in % of Sr) | 5 % |
| Rated operating current | 200 mA |
Outputs:-
| Number of digital switching outputs | 1 Piece(s) |
Switching Outputs:-
| Type | Digital switching output |
| Voltage type | DC |
Switching Outputs 1:-
| Switching element | Transistor, NPN |
| Switching principle | NC (normally closed) |
Time Behavior:-
| Switching frequency | 100 Hz |
Connection:-
| Number of connections | 1 Piece(s) |
Connection 1:-
| Function | Signal OUT Voltage supply |
| Type of connection | Cable |
| Cable length | 2,000 mm |
| Sheathing material | PVC |
| Number of conductors | 3 -wire |
| Wire cross section | 0.35 mm² |
Mechanical Data:-
| Design | Cylindrical |
| Thread size | M30 x 1.5 mm |
| Dimension (Ø x L) | 30 mm x 85 mm |
| Type of installation | Embedded |
| Housing material | Plastic |
| Plastic housing | Polybutylene (PBT) |
| Sensing face material | Plastic, Polybutylene (PBT) |
| Cover material | Plastic, Polybutylene (PBT) |
Operation & Display:-
| Type of display | LED |
| Number of LEDs | 1 Piece(s) |
| Operational controls | Multiturn potentiometer |
| Function of the operational control | Sensitivity adjustment |
| Switching distance, adjustable | Yes |
Environmental Data:-
| Ambient temperature, operation | -25 … 70 °C |
Data Sheet: Pdf
Model:-
Available Stocks In Bangladesh
LCS-2M30P-F20NNO-K020V, 50136563
LCS-2M30P-F20NNC-K020V, 50136564
LCS-2M18P-F08PNO-K020V, 50136545
LCS-2M18P-F08NNC-K020V, 50136548
