Leuze Inductive Proximity Sensor IS 112 MM/2NO-8N0 , 50129872
Basic Data:-
| Series | 112 |
| Typ. operating range limit Sn | 8 mm |
| Operating range Sa | 0 … 6.4 mm |
Electrical Data:-
| Protective circuit | Overload protection Polarity reversal protection Short circuit protected |
Performance Data:-
| Supply voltage UB | 10 … 30 V, DC |
| Residual ripple | 10 %, From UB |
| Open-circuit current | 0 … 10 mA |
| Temperature drift, max. (in % of Sr) | 10 % |
| Repeatability, max. (in % of Sr) | 1 % |
| Switching hysteresis | 15 % |
Outputs:-
| Number of digital switching outputs | 1 Piece(s) |
Switching Outputs:-
| Voltage type | DC |
| Switching current, max. | 200 mA |
| Residual current, max. | 0.01 mA |
| Voltage drop | ≤ 2 V |
Switching Outputs 1:-
| Switching element | Transistor, NPN |
| Switching principle | NO (normally open) |
Time Behavior:-
| Switching frequency | 500 Hz |
Connection:-
| Number of connections | 1 Piece(s) |
Connection 1:-
| Function | Signal OUT Voltage supply |
| Type of connection | Cable |
| Cable length | 2,000 mm |
| Sheathing material | PVC |
| Cable color | Black |
| Number of conductors | 3 -wire |
| Wire cross section | 0.35 mm² |
Mechanical Data:-
| Design | Cylindrical |
| Thread size | M12 x 1 mm |
| Dimension (Ø x L) | 12 mm x 50 mm |
| Type of installation | Non-embedded |
| Housing material | Metal |
| Metal housing | Nickel-plated brass |
| Sensing face material | Plastic, Polybutylene (PBT) |
| Housing color | Red, RAL 3000 Silver |
| Type of fastening | Mounting thread |
| Standard measuring plate | 24 x 24 mm², Fe360 |
Operation & Display:-
| Type of display | LED |
| Number of LEDs | 1 Piece(s) |
Environmental Data:-
| Ambient temperature, operation | -25 … 70 °C |
| Ambient temperature, storage | -25 … 70 °C |
MODEL:-
ISS 112MM/4NC-6E0-M12 ; Part no.: 50136037,ISS 112MM/4NO-6E0-M12 ; Part no.: 50136036,ISS 112MM/2NC-6E0-M12 ; Part no.: 50136035,ISS 112MM/2NO-6E0-M12 ; Part no.: 50136034,ISS 112MM/4NC-4E0-M12 ; Part no.: 50136033,ISS 112MM/4NO-4E0-M12 ; Part no.: 50136032,ISS 112MM/2NC-4E0-M12 ; Part no.: 50136031,ISS 112MM/2NO-4E0-M12 ; Part no.: 50136030,ISS 112MM/4NC-6E0 ; Part no.: 50136029,ISS 112MM/4NO-6E0 ; Part no.: 50136028,ISS 112MM/2NC-6E0 ; Part no.: 50136027,ISS 112MM/2NO-6E0 ; Part no.: 50136026,ISS 112MM/4NC-4E0 ; Part no.: 50136025,ISS 112MM/4NO-4E0 ; Part no.: 50136024,ISS 112MM/2NC-4E0 ; Part no.: 50136023,ISS 112MM/2NO-4E0 ; Part no.: 50136022,ISS 112MM/4NC-8N0-M12 ; Part no.: 50136021,ISS 112MM/4NO-8N0-M12 ; Part no.: 50136020,ISS 112MM/2NC-8N0-M12 ; Part no.: 50136019,ISS 112MM/2NO-8N0-M12 ; Part no.: 50136018,ISS 112MM/4NC-8N0 ; Part no.: 50136017,ISS 112MM/4NO-8N0 ; Part no.: 50136016,ISS 112MM/2NC-8N0 ; Part no.: 50136015,ISS 112MM/2NO-8N0 ; Part no.: 50136014,
IS 112MM/2NO-4E0-PUR ; Part no.: 50134444,IS 112MM/4NO-4E0-PUR ; Part no.: 50134443,IS 112 MM/4NC-8N0-M12; Part no.: 50129887,IS 112 MM/4NO-8N0-M12 ; Part no.: 50129886,IS 112 MM/2NC-8N0-M12 ; Part no.: 50129885,IS 112 MM/2NO-8N0-M12 ; Part no.: 50129884,IS 112 MM/4NC-6E0-M12 ; Part no.: 50129883,IS 112 MM/4NO-6E0-M12 ; Part no.: 50129882,IS 112 MM/2NC-6E0-M12 ; Part no.: 50129881,IS 112 MM/2NO-6E0-M12 ; Part no.: 50129880,
IS 112 MM/4NC-4E0-M12 ; Part no.: 50129879,IS 112 MM/4NO-4E0-M12 ; Part no.: 50129878,IS 112 MM/2NC-4E0-M12 ; Part no.: 50129877,IS 112 MM/2NO-4E0-M12 ; Part no.: 50129876,IS 112 MM/4NC-8N0 ; Part no.: 50129875,
IS 112 MM/4NO-8N0 ; Part no.: 50129874,IS 112 MM/2NC-8N0 ; Part no.: 50129873,IS 112 MM/2NO-8N0 ; Part no.: 50129872,IS 112 MM/4NC-6E0 ; Part no.: 50129871,IS 112 MM/4NO-6E0 ; Part no.: 50129870,IS 112 MM/2NC-6E0 ; Part no.: 50129869,IS 112 MM/2NO-6E0 ; Part no.: 50129868,IS 112 MM/4NC-4E0 ; Part no.: 50129867,IS 112 MM/4NO-4E0 ; Part no.: 50129866,IS 112 MM/2NC-4E0 ; Part no.: 50129865,IS 112 MM/2NO-4E0 ; Part no.: 50129864,
ISS 212MM/2NO-4E0 ; Part no.: 50145947,ISS 212MM/44-8N0-S12 ; Part no.: 50141477,ISS 212MM/44-8N0 ; Part no.: 50141476,ISS 212MM/44-4E0-S12 ; Part no.: 50141475,ISS 212MM/44-4E0 ; Part no.: 50141474,ISS 212MM/44-4N0-S12 ; Part no.: 50141473,ISS 212MM/44-4N0 ; Part no.: 50141472,ISS 212MM/44-2E0-S12 ; Part no.: 50141471,ISS 212MM/44-2E0 ; Part no.: 50141470,
ISS 212MM/4NC-6E0-S12 ; Part no.: 50133409,IS 212MM/2NC-2E0 ; Part no.: 50129415,ISS 212MM/4NC-4E0 ; Part no.: 50129359,IS 212MM/4NC-8N0-S12 ; Part no.: 50129358,IS 212MM/4NC-8N0 ; Part no.: 50129357,IS 212MM/2NC-8N0 ; Part no.: 50129356,IS 212MM/4NC-10N ; Part no.: 50129355,IS 212MM/2NO-4E0-S12 ; Part no.: 50129354,IS 212MM/4NC-4E0 ; Part no.: 50129353,IS 212MM/2NC-4N0 ; Part no.: 50129352,IS 212MM/4NC-4N0 ; Part no.: 50129351,
IS 212MM/4NC-2E0 ; Part no.: 50129350,IS 212MM/2NC-4N0-S12 ; Part no.: 50121012,IS 212MM/2NO-8N0-S12 ; Part no.: 50120274,IS 212MM/2NC-4E0 ; Part no.: 50114380,IS 212MM/4NC-10N-S12 ; Part no.: 50114052,IS 212MM/4NC-4N0-S12 ; Part no.: 50112914,IS 212MM/4NO-8N0-S12 ; Part no.: 50112808,
IS 212MM/4NO-8N0 ; Part no.: 50112807,IS 212MM/2NO-8N0 ; Part no.: 50112806,ISS 212MM/2NO-4N0 ; Part no.: 50112209,ISS 212MM/4NO-4N0-S12 ; Part no.: 50111963,IS 212MM/2NO-10N ; Part no.: 50111952,IS 212MM/4NC-2E0-S12 ; Part no.: 50111870,ISS 212MM/2NC-4E0-S12 ; Part no.: 50111741,IS 212MM/4NO-10N ; Part no.: 50109689,ISS 212MM/2NO-6E0-S12 ; Part no.: 50109688,ISS 212MM/2NO-4E0-S12 ; Part no.: 50109687,ISS 212MM/4NO-4E0-S12 ; Part no.: 50109685,ISS 212MM/4NO-4E0 ; Part no.: 50109684,IS 212MM/2NO-6E0 ; Part no.: 50109682,ISS 212MM/4NO-10N-S12 ; Part no.: 50109680,ISS 212MM/4NO-6E0-S12 ; Part no.: 50109679,IS 212MM/4NO-6E0 ; Part no.: 50109678,IS 212MM/2NC-4E0-S12 ; Part no.: 50109677,ISS 212MM/4NC-4E0-S12 ; Part no.: 50109676,IS 212MM/2NO-4E0 ; Part no.: 50109675,IS 212MM/4NC-4E0-S12 ; Part no.: 50109674,IS 212MM/4NO-4E0-S12 ; Part no.: 50109673,IS 212MM/4NO-4E0 ; Part no.: 50109672,IS 212MM/2NO-4N0-S12 ; Part no.: 50109671,IS 212MM/2NO-4N0 ; Part no.: 50109670,
IS 212MM/4NO-4N0-S12 ; Part no.: 50109669,IS 212MM/4NO-4N0 ; Part no.: 50109668,IS 212MM/2NO-2E0 ; Part no.: 50109666,IS 212MM/4NO-2E0-S12 ; Part no.: 50109665,IS 212MM/4NO-2E0 ; Part no.: 50109664,IS 212FM/2NO.5-3E0 ; Part no.: 50128178,IS 212FM/2NO.5-3E0-S12 ; Part no.: 50128177,IS 212FM/4NO.5-3E0 ; Part no.: 50128176,IS 212FM/4NO.5-3E0-S12 ; Part no.: 50128175,IS 212FM/4NC.5-3E0-S12 ; Part no.: 50128173,IS 212FM/4NO.5F-10N-S12 ; Part no.: 50109738,IS 212FM/4NO.5F-6E0-S12 ; Part no.: 50109736,IS 212MM/1NO.3-2E0 ; Part no.: 50128150,IS 212MM/1NC.3-2E0 ; Part no.: 50128149.
