Leuze Inductive Proximity Sensor IS 118 MM/2NO-8E0 , 50129843

In Stock
Highlights:
  • DIA: 18MM
  • RANGE: 8MM
  • OUTPUT: NPN-NO
  • SUPPLY VOLTAGE: 10-30VDC
  • CABLE TYPE
  • 3-WIRE
  • METAL HOUSING
  • EMBEDDED
Compare
Estimated Delivery: 1-3 Days
21 June - 23 June
Description

Leuze Inductive Proximity Sensor IS 118 MM/2NO-8E0 , 50129843

Inductive Proximity Sensor

Basic Data:-

Series 118
Typ. operating range limit Sn 8 mm
Operating range Sa 0 … 6.5 mm

Electrical Data:-

Protective circuit Overload protection
Polarity reversal protection
Short circuit protected

Performance Data:-

Supply voltage UB 10 … 30 V, DC
Residual ripple 10 %, From UB
Open-circuit current 0 … 10 mA
Temperature drift, max. (in % of Sr) 10 %
Repeatability, max. (in % of Sr) 1 %
Switching hysteresis 15 %

Outputs:-

Number of digital switching outputs 1 Piece(s)

Switching Outputs:-

Voltage type DC
Switching current, max. 200 mA
Residual current, max. 0.01 mA
Voltage drop ≤ 2 V

Switching Outputs 1:-

Switching element Transistor, NPN
Switching principle NO (normally open)

Time Behavior:-

Switching frequency 3,000 Hz

Connection:-

Number of connections 1 Piece(s)

Connection 1:-

Function Signal OUT
Voltage supply
Type of connection Cable
Cable length 2,000 mm
Sheathing material PVC
Cable color Black
Number of conductors 3 -wire
Wire cross section 0.35 mm²

Mechanical Data:-

Design Cylindrical
Thread size M18 x 1 mm
Dimension (Ø x L) 18 mm x 55 mm
Type of installation Embedded
Housing material Metal
Metal housing Nickel-plated brass
Sensing face material Plastic, Polybutylene (PBT)
Housing color Red, RAL 3000
Silver
Type of fastening Mounting thread
Standard measuring plate 24 x 24 mm², Fe360

Operation & Display:-

Type of display LED
Number of LEDs 1 Piece(s)

Environmental Data:-

Ambient temperature, operation -25 … 70 °C
Ambient temperature, storage -25 … 70 °C

MODEL:-

ISS 118MM/4NC-8E0-M12 ; Part no.: 50144726,ISS 118MM/4NO-16N-M12 ; Part no.: 50136057,ISS 118MM/2NO-16N-M12 ; Part no.: 50136056,ISS 118MM/4NO-16N ; Part no.: 50136055,ISS 118MM/2NO-16N ; Part no.: 50136054,
ISS 118MM/4NO-8E0-M12 ; Part no.: 50136013,ISS 118MM/2NO-8E0-M12 ; Part no.: 50136012,ISS 118MM/4NO-8E0 ; Part no.: 50136011,ISS 118MM/2NO-8E0 ; Part no.: 50136010,IS 118MM/4NC-16N-M12 ; Part no.: 50129987,IS 118 MM/4NO-16N-M12 ; Part no.: 50129985,IS 118MM/2NC-16N-M12 ; Part no.: 50129984,IS 118 MM/2NO-16N-M12 ; Part no.: 50129983,IS 118 MM/4NC-8E0-M12 ; Part no.: 50129982,IS 118 MM/4NO-8E0-M12 ; Part no.: 50129981,
IS 118 MM/2NC-8E0-M12 ; Part no.: 50129980,IS 118 MM/2NO-8E0-M12 ; Part no.: 50129979,IS 118MM/4NC-16N ; Part no.: 50129978,IS 118MM/4NO-16N ; Part no.: 50129977,IS 118MM/2NC-16N ; Part no.: 50129961,IS 118MM/2NO-16N ; Part no.: 50129960,IS 118 MM/4NC-8E0 ; Part no.: 50129857,IS 118 MM/4NO-8E0 ; Part no.: 50129856,IS 118 MM/2NC-8E0 ; Part no.: 50129854,IS 118 MM/2NO-8E0 ; Part no.: 50129843,ISS 218MM/2NO-8E0 ; Part no.: 50145949,ISS 218MM/4NO-8E0 ; Part no.: 50145948,ISS 218MM/44-14N-S12 ; Part no.: 50141485,ISS 218MM/44-14N ; Part no.: 50141484,ISS 218MM/44-8E0-S12 ; Part no.: 50141483,ISS 218MM/44-8E0 ; Part no.: 50141482,ISS 218MM/44-8N0-S12 ; Part no.: 50141481,ISS 218MM/44-8N0 ; Part no.: 50141480,ISS 218MM/44-5E0-S12 ; Part no.: 50141479,ISS 218MM/44-5E0 ; Part no.: 50141478,IS 218MM/4NC-12N-S12 ; Part no.: 50135397,ISS 218MM/4NC-8E0-200-S12 ; Part no.: 50135195,ISS 218MM/4NO-8E0-200-S12 ; Part no.: 50135194,IS 218MM/4NO-12N-S12 ; Part no.: 50134095,ISS 218MM/4NC-5E0-S12 ; Part no.: 50129368,IS 218MM/2NC-8E0 ; Part no.: 50129367,IS 218 MM/4NC-12E-S12 ; Part no.: 50129366,IS 218MM/4NC-20N ; Part no.: 50129365,IS 218MM/4NC-8E0 ; Part no.: 50129364,IS 218MM/2NC-8N0-S12 ; Part no.: 50129363,IS218MM/2NC-8N0 ; Part no.: 50129362,IS 218MM/4NC-8N0-S12 ; Part no.: 50129361,IS 218MM/4NC-8N0 ; Part no.: 50129360,IS 218MM/4NC-5E0-S12 ; Part no.: 50127466,ISS 218MM/4NC-12E-S12 ; Part no.: 50120273,IS 218MM/4NC-5E0 ; Part no.: 50118521,IS 218MM/4NO-12E-S12 ; Part no.: 50114427,ISS 218MM/4NO-5E0 ; Part no.: 50112915,ISS 218MM/4NO-5E0-S12 ; Part no.: 50112293,IS 218MM/2NO-8E0 ; Part no.: 50112104,IS 218MM/2NO-12E ; Part no.: 50111954,IS 218MM/2NO-20N ; Part no.: 50111953,ISS 218MM/2NC-8E0-S12 ; Part no.: 50111745,ISS 218MM/4NC-8E0-S12 ; Part no.: 50111744,
ISS 218MM/4NO-8E0-S12 ; Part no.: 50111743,ISS 218MM/4NC-20N-S12 ; Part no.: 50109711,ISS 218MM/4NO-20N-S12 ; Part no.: 50109710,IS 218MM/4NO-20N ; Part no.: 50109709,ISS 218MM/2NO-12E-S12 ; Part no.: 50109708,ISS 218MM/4NO-12E-S12 ; Part no.: 50109707,IS 218MM/4NO-12E ; Part no.: 50109706,IS 218MM/2NC-8E0-S12 ; Part no.: 50109705,IS 218MM/2NO-8E0-S12 ; Part no.: 50109704,ISS 218MM/2NO-8E0-S12 ; Part no.: 50109703,
IS 218MM/4NC-8E0-S12 ; Part no.: 50109702,IS 218MM/4NO-8E0-S12 ; Part no.: 50109701,IS 218MM/4NO-8E0 ; Part no.: 50109700,IS 218MM/2NO-8N0-S12 ; Part no.: 50109699,IS 218MM/2NO-8N0 ; Part no.: 50109698,IS 218MM/4NO-8N0-S12 ; Part no.: 50109697,IS 218MM/4NO-8N0 ; Part no.: 50109696,IS 218MM/2NO-5E0 ; Part no.: 50109694,IS 218MM/4NO-5E0-S12 ; Part no.: 50109693,IS 218MM/4NO-5E0 ; Part no.: 50109692,IS 218FM/4NC.5-5E0 ; Part no.: 50138121,IS 218FM/2NO.5-5E0 ; Part no.: 50128172,IS 218FM/2NO.5-5E0-S12 ; Part no.: 50128171,IS 218FM/4NO.5-5E0 ; Part no.: 50128170,IS 218FM/4NO.5-5E0-S12 ; Part no.: 50128169,IS 218FM/4NO.5F-20N-S12 ; Part no.: 50109734,IS 218FM/4NO.5F-10E-S12 ; Part no.: 50109732,IS 218MM/1NO.3-5E0 ; Part no.: 50128152,IS 218MM/1NC.3-5E0 ; Part no.: 50128151.

Data Sheet: Pdf
