LCS-2M18P-F08NNO-K020V, 50136547 Leuze Capacitive Sensor

In Stock
Highlights:
  • DIA: 18MM
  • RANGE: 2-8MM
  • OUTPUT: NPN-NO
  • SUPPLY VOLTAGE: 10-30VDC
  • CABLE TYPE
  •  3-WIRE
  • PLASTIC HOUSING
  • EMBEDDED
Compare
Estimated Delivery: 1-3 Days
15 June - 17 June
Description

LCS-2M18P-F08NNO-K020V, 50136547 Leuze Capacitive Sensor

Capacitive Sensor

Specifications:-

Basic Data:-

Series LCS-2
Switching distance Sn 2 … 8 mm
Assured switching distance 6.5 mm

Electrical Data:-

Protective circuit Polarity reversal protection
Short circuit protected

Performance Data:-

Supply voltage UB 10 … 30 V, DC
Residual ripple 0 … 10 %
Open-circuit current 10 mA
Temperature drift, max. (in % of Sr) 10 %
Repeatability, max. (in % of Sr) 5 %
Rated operating current 200 mA

Outputs:-

Number of digital switching outputs 1 Piece(s)

Switching Outputs:-

Type Digital switching output
Voltage type DC

Switching Outputs 1:-

Switching element Transistor, NPN
Switching principle NO (normally open)

Time Behavior:-

Switching frequency 100 Hz

Connection:-

Number of connections 1 Piece(s)

Connection 1:-

Function Signal OUT
Voltage supply
Type of connection Cable
Cable length 2,000 mm
Sheathing material PVC
Number of conductors 3 -wire
Wire cross section 0.35 mm²

Mechanical Data:-

Design Cylindrical
Thread size M18 x 1 mm
Dimension (Ø x L) 18 mm x 70 mm
Type of installation Embedded
Housing material Plastic
Plastic housing Polybutylene (PBT)
Sensing face material Plastic, Polybutylene (PBT)
Cover material Plastic, Polybutylene (PBT)

Operation & Display:-

Type of display LED
Number of LEDs 1 Piece(s)
Operational controls Multiturn potentiometer
Function of the operational control Sensitivity adjustment
Switching distance, adjustable Yes

Environmental Data:-

Ambient temperature, operation -25 … 70 °C

Data Sheet: Pdf
