ET5.3/4P, 50122579 Leuze Energetic Diffuse Sensor

In Stock
Highlights:
  • RANGE: 0-1m
  • OUTPUT: PNP-LIGHT SWITCHING /DARK SWITCHING
  • SUPPLY VOLTAGE: 10-30VDC
  • CABLE TYPE
  • 4 WIRE
  • PLASTIC HOUSING
Compare
Estimated Delivery: 1-3 Days
15 June - 17 June
Description

ET5.3/4P, 50122579 Leuze Energetic Diffuse Sensor

Diffuse Sensor

Specifications:-

Basic Data:-

Series 5
Operating principle Diffuse reflection principle

Optical Data:-

Operating range Guaranteed operating range
Operating range, white 90% 0.001 … 0.7 m
Operating range, gray 50% 0.001 … 0.59 m
Operating range, gray 18% 0.003 … 0.39 m
Operating range, black 6% 0.005 … 0.28 m
Operating range limit Typical operating range
Operating range limit, white 90% 0 … 1 m
Operating range limit, gray 50% 0.001 … 0.85 m
Operating range limit, gray 18% 0.003 … 0.55 m
Operating range limit, black 6% 0.002 … 0.4 m
Light source LED, Red
Wavelength 620 nm
LED group Exempt group (in acc. with EN 62471)

Electrical Data:-

Protective circuit Polarity reversal protection
Short circuit protected

Performance Data:-

Supply voltage UB 10 … 30 V, DC, Incl. residual ripple
Residual ripple 0 … 15 %, From UB
Open-circuit current 0 … 20 mA

Outputs:-

Number of digital switching outputs 2 Piece(s)

Switching Outputs 1-

Switching element Transistor, PNP
Switching principle Light switching

Switching Outputs 2:-

Switching element Transistor, PNP
Switching principle Dark switching

Time Behavior:-

Switching frequency 500 Hz
Response time 1 ms
Readiness delay 300 ms

Connection:-



Connection 1:-

Function Signal OUT
Voltage supply
Type of connection Cable
Cable length 2,000 mm
Sheathing material PUR
Cable color Black
Number of conductors 4 -wire
Wire cross section 0.2 mm²

Mechanical Data:-

Dimension (W x H x L) 14 mm x 32.5 mm x 20.2 mm
Housing material Plastic
Plastic housing ABS
Lens cover material Plastic
Net weight 70 g
Housing color Black
Red

Operation & Display:-

Type of display LED
Operational controls Teach button

Environmental Data:-

Ambient temperature, operation -40 … 60 °C
Ambient temperature, storage -40 … 70 °C

Data Sheet: Pdf

Similar Model:-

HT25CI.HFXF/4P,SETHT25CI-450F.HF/4P410M12 BTX,,HT25CI-450F.HF/4P-410-M12,SETHT25CI-300F.HF/4P410M12 BTX,HT25CI-300F.HF/4P-410-M12,SETHT25CI-300F.HF/PX200M12 BTX,HT25CI-300F.HF/PX-200-M12,HT3CI.HF/4X-M8,ODT25B/L6.32-2500,200-S12,ODT25B/L6X.32-2500-S12,HT55C.V/LG-200-M12,ODT55C.S3/L6-M8,ODT55C.3/L6-M8,HT55CL1/LG-5000,HT55CL1/LG-5000,HT55CL1/LG-200-M12,HT55CL1/LG-M8,HT55C/LG-5000,HT55C/LG-200-M12,HT55C/LG-M8,HT55CI/LG-200-M12,,ODT53C.S3/L6-M8,ODT53C.3/L6-M8,HT5BI/4,HT5B/PX-200-M12,HT5B/4X-200-M12,HT5B/4-M8.3,HT5B/PX-M8 ,HT5B/4X-M8,HT5B/2X-M8,HT5B/P,HT5B/4,HT5B/2.

Scroll To Top
Close
Close
Close

My Cart

Shopping cart is empty!

Continue Shopping

Energetic diffuse sensor
