Leuze Rotary Encoder EI 1058-S10x20C-2500H-020R , 50140919

In Stock
Highlights:
  • Type: Incremental rotary encoder
  • Max. operating speed: 6,000 r/min
  • Resolution : 2,500 p/r
  • Supply voltage : 5 … 28 VDC , HTL
  • Type of connection : Cable
  • Cable length : 2m
  • Connector : radial
  • Sheathing material : PVC
  • Cable color : Gray , 8 -wire
Compare
Estimated Delivery: 1-3 Days
15 June - 17 June
Description

Leuze Rotary Encoder EI 1058-S10x20C-2500H-020R,50140919

Rotary encoder

Technical data:-

Measurement data:-

Max. operating speed 6,000 r/min
Resolution 2,500 p/r

Electrical data:-

Protective circuit Polarity reversal protection
Short circuit protected

    Performance data:-

Supply voltage UB 5 … 28 V, DC
Open-circuit current 0 … 150 mA

Time behavior:-

Switching frequency 300,000 Hz

Interface:-

Type HTL

Connection:-

Function Signal OUT
Voltage supply
Type of connection Cable
Cable length 2,000 mm
Connector radial
Sheathing material PVC
Cable color Gray
Number of conductors 8 -wire
Wire cross section 0.14 mm²

Mechanical data:-

Housing material Metal
Metal housing Aluminum
Flange type Clamping flange

Shaft:-

Design Shaft
Dimension (Ø x L) 10 mm
Dimension (Ø x L) 20 mm
Start-up torque 0.5 N·m
Shaft load – axial 60 N
Shaft load – radial 120 N

Environmental data:-

Ambient temperature, operation -40 … 70 °C
Ambient temperature, storage -40 … 70 °C

Another Model:-

EI 1058-T10S-1024T-020R,

EI 1058-T10S-1024T-020R,
EI 1058-T10S-0360H-050R,
EI 1058-T10S-3600H-050R,
EI 1058-T12S-5000H-020R,
EI 1058-T12S-1024H-020R,
EI 1058-T12S-1024H-020R,
EI 1058-T14S-0360H-050R,
EI 1058-T10S-1024H-050R,
EI 1058-T14S-1000H-M23R,
EI 1058-T08S-1024H-020R,
EI 1058-S08x20Q-0100H-050R,
EI 1058-S10x20C-0050H-050A,
EI 1058-S08x20C-2000H-020A,
EI 1058-S08x20C-0100H-020R,
EI 1058-S10x20C-0360H-050R,
EI 1058-S10x20C-2048T-050R,
EI 1058-S08x20C-2500H-050R,
EI 1058-S10x20C-2500H-M23R,
EI 1058-S10x20C-5000H-050R,
EI 1058-S08x20C-2500T-020R,
EI 1058-S10x20C-2500H-050A,

Data Sheet:-PDF
