IPRK 18/A.1 L.4, 50034119 Leuze Photoelectric Sensor

In Stock
Highlights:
  • RANGE: 0-2.4m
  • SUPPLY VOLTAGE: 26.5 -31.6 VDC
  • M12 CONNECTOR
  • 4-PIN
  • AS-INTERFACE IO
  • METAL HOUSING
Compare
Estimated Delivery: 1-3 Days
15 June - 17 June
Description

IPRK 18/A.1 L.4, 50034119 Leuze Photoelectric Sensor

Polarized Retro-Reflective Photoelectric Sensor

Basic Data:-

Series 18
Operating principle Reflection principle
Application Detection of highly transparent bottles
Detection of highly transparent films and glass panes

Special Version:-

Special version Autocollimation
Warning output

Optical Data:-

Operating range 0 … 2.4 m
Operating range Guaranteed operating range
Operating range limit Typical operating range
Operating range limit 0 … 3 m
Light source LED, Red
Wavelength 660 nm
LED group 1
Type of light spot geometry Round

Electrical Data:-

Protective circuit Polarity reversal protection
Short circuit protected

Performance Data:-

Supply voltage UB 26.5 … 31.6 V
Open-circuit current 0 … 35 mA

Time Behavior:-

Switching frequency 500 Hz
Response time 1 ms
Readiness delay 300 ms

Interface:-

Type AS-Interface IO

Connection:-

Connection 1:-

Function AS-i interface
Voltage supply
Type of connection Connector
Thread size M12
Type Male
Material Stainless steel
No. of pins 4 -pin
Encoding A-coded

Mechanical Data:-

Dimension (W x H x L) 15 mm x 50 mm x 33 mm
Housing material Metal
Metal housing Zinc
Lens cover material Glass
Net weight 75 g
Housing color Red
Type of fastening Mounting thread
Through-hole mounting

Operation & Display:-

Type of display LED
Operational controls Multiturn potentiometer

Environmental Data:-

Ambient temperature, operation -25 … 55 °C
Ambient temperature, storage -40 … 70 °C

Data Sheet: Pdf
