GS 61/6, 50110769 Leuze Fork Photoelectric Sensor

In Stock
Highlights:
  • Label width
  • min. : 2 mm
  • Label gap
  • min. : 2 mm
  • Medium: Not transparent
  • Transistor
  • Push-pull
  • switching in the gap



Compare
Estimated Delivery: 1-3 Days
15 June - 17 June
Description

GS 61/6, 50110769 Leuze Fork Photoelectric Sensor

Fork Photoelectric Sensor

Specifications:-

Basic Data:-

Series 61
Principle of physics Optical
Application Detection of non-transparent labels
Label width, min. 2 mm
Label gap, min. 2 mm
Medium Not transparent

Optical Data:-

Light source LED, Infrared
Wavelength 940 nm

Electrical Data:-

Protective circuit Polarity reversal protection
Short circuit protected

Performance Data:-

Supply voltage UB 10 … 30 V, DC
Residual ripple 0 … 15 %, From UB
Open-circuit current 0 … 30 mA

Outputs:-

Number of digital switching outputs 1 Piece(s)

Switching Outputs:-

Type Digital switching output
Voltage type DC
Switching current, max. 100 mA
Switching voltage high: ≥(UB-2V)
low: ≤ 2 V

Switching Outputs 1:-

Switching element Transistor, Push-pull
Switching principle Switching signal in label gap

Time Behavior:-

Switching frequency 10,000 Hz
Response time 0.05 ms
Readiness delay 300 ms
Max. conveyor speed during teach-in 20 m/min

Connection:-

Number of connections 1 Piece(s)

Connection 1:-

Function Signal OUT
Voltage supply
Type of connection Cable
Cable length 2,000 mm
Number of conductors 5 -wire

Mechanical Data:-

Design Fork
Mouth width 3 mm
Mouth depth 41 mm
Dimension (W x H x L) 11 mm x 30 mm x 60 mm
Housing material Plastic
Plastic housing PC
Lens cover material Plastic/PC
Net weight 70 g
Housing color Black, RAL 9005
Red, RAL 3000
Type of fastening Mounting thread
Through-hole mounting
Via optional mounting device

Operation & Display:-

Type of display LED
Number of LEDs 2 Piece(s)
Operational controls Multiturn potentiometer

Environmental Data:-

Ambient temperature, operation -20 … 60 °C
Ambient temperature, storage -30 … 70 °C

Data Sheet: Pdf
