IS 212MM/1NC.3-2E0,50128149 Leuze Inductive Proximity Sensor

In Stock
Highlights:
  • DIA: 12MM
  • SN: 2MM
  • NC
  • SUPPLY VOLTAGE: 10-320 V
  • AC/DC, CABLE TYPE
  • 2 WIRE
  • METAL HOUSING
  • EMBEDDED
Compare
Estimated Delivery: 1-3 Days
15 June - 17 June
Description

IS 212MM/1NC.3-2E0,50128149 Leuze Inductive Proximity Sensor

Inductive Proximity Sensor

Specifications:-

Basic Data:-

Series 212
Typ. operating range limit Sn 2 mm
Operating range Sa 0 … 1.6 mm

Mesurement Data :-

Repeatability 0.5 mm

Electrical Data:-

Protective circuit Inductive protection
Polarity reversal protection
Short circuit protected

Performance Data:-

Supply voltage UB 10 … 320 V, AC/DC
Residual ripple 0 … 20 %, From UB
Open-circuit current 0 … 1 mA
Temperature drift, max. (in % of Sr) 10 %, Over the entire operating temperature range
Repeatability, max. (in % of Sr) 5 %, For UB = 20 … 30 V DC, ambient temperature Ta = 23 °C ± 5 °C
Switching hysteresis 20 %

Outputs:-

Number of digital switching outputs 1 Piece(s)

Switching Outputs:-

Voltage type AC/DC
Switching current, max. 200 mA
Voltage drop ≤ 2 V

Switching Outputs 1:-

Switching element Relay, NC
Switching principle NC (normally closed)

Time Behavior:-

Switching frequency 3,000 Hz
Oscillator frequency 350,000 Hz
Readiness delay 10 ms

Connection:-

Number of connections 1 Piece(s)

Connection 1:-

Function Voltage supply
Type of connection Cable
Cable length 2,000 mm
Sheathing material PVC
Cable color Black
Number of conductors 2 -wire
Wire cross section 0.34 mm²

Mechanical Data:-

Design Cylindrical
Thread size M12 x 1 mm
Dimension (Ø x L) 12 mm x 52 mm
Type of installation Embedded
Housing material Metal
Metal housing Chromed brass
Sensing face material Plastic, Polybutylene (PBT)
Net weight 93 g
Housing color Red, RAL 3000
Silver
Type of fastening Mounting thread
Via optional mounting device
Standard measuring plate 12 x 12 mm², Fe360

Operation & Display:-

Type of display LED
Number of LEDs 1 Piece(s)

Environmental Data:-

Ambient temperature, operation -25 … 70 °C

Data Sheet: Pdf

Other Model :-

S 212MM/2NO-4E0 ; Part no.: 50109675
IS 212MM/4NC-4E0-S12 ; Part no.: 50109674
IS 212MM/4NO-4E0-S12 ; Part no.: 50109673
IS 212MM/4NO-4E0 ; Part no.: 50109672
IS 212MM/2NO-4N0-S12 ; Part no.: 50109671
IS 212MM/2NO-4N0 ; Part no.: 50109670
IS 212MM/4NO-4N0-S12 ; Part no.: 50109669
IS 212MM/4NO-4N0 ; Part no.: 50109668
IS 212MM/2NO-2E0 ; Part no.: 50109666
IS 212MM/4NO-2E0-S12 ; Part no.: 50109665
IS 212MM/4NO-2E0 ; Part no.: 50109664
IS 212FM/2NO.5-3E0 ; Part no.: 50128178
IS 212FM/2NO.5-3E0-S12 ; Part no.: 50128177
IS 212FM/4NO.5-3E0 ; Part no.: 50128176
IS 212FM/4NO.5-3E0-S12 ; Part no.: 50128175
IS 212FM/4NC.5-3E0-S12 ; Part no.: 50128173
IS 212FM/4NO.5F-10N-S12 ; Part no.: 50109738
IS 212FM/4NO.5F-6E0-S12 ; Part no.: 50109736
IS 212MM/1NO.3-2E0 ; Part no.: 50128150
IS 212MM/1NC.3-2E0 ; Part no.: 50128149
