IS 218MM/1NC.3-5E0, 50128151 Leuze Inductive Proximity Sensor

In Stock
Highlights:
  • DIA: 18MM
  • SN: 5MM
  • NC
  • SUPPLY VOLTAGE: 10-320 V
  • AC/DC
  • CABLE TYPE
  • 2 WIRE
  • METAL HOUSING



  • EMBEDDED
Compare
Estimated Delivery: 1-3 Days
15 October - 17 October
Description

IS 218MM/1NC.3-5E0, 50128151 Leuze Inductive Proximity Sensor

Inductive Proximity Sensor

Specifications:-

Basic Data:-

Series 218
Typ. operating range limit Sn 5 mm
Operating range Sa 0 … 4 mm

Measurement Data:-

Repeatability 0.5 mm

Electrical Data:-

Protective circuit Inductive protection
Polarity reversal protection
Short circuit protected

Performance Data:-

Supply voltage UB 10 … 320 V, AC/DC
Residual ripple 0 … 20 %, From UB
Open-circuit current 0 … 1 mA
Temperature drift, max. (in % of Sr) 10 %, Over the entire operating temperature range
Switching hysteresis 20 %

Outputs:-

Number of digital switching outputs 1 Piece(s)

Switching Outputs:-

Voltage type AC/DC
Switching current, max. 200 mA
Voltage drop ≤ 2 V

Switching Outputs 1:-

Switching element Relay, NC
Switching principle NC (normally closed)

Time Behavior:-

Switching frequency 1,500 Hz
Oscillator frequency 175,000 Hz
Readiness delay 70 ms

Connection:-

Number of connections 1 Piece(s)

Connection 1:-

Function Voltage supply
Type of connection Cable
Cable length 2,000 mm
Sheathing material PVC
Cable color Black
Number of conductors 2 -wire
Wire cross section 0.34 mm²

Mechanical Data:-

Design Cylindrical
Thread size M18 x 1 mm
Dimension (Ø x L) 18 mm x 50 mm
Type of installation Embedded
Housing material Metal
Metal housing Chromed brass
Sensing face material Plastic, Polybutylene (PBT)
Net weight 116 g
Housing color Red, RAL 3000
Silver
Type of fastening Mounting thread
Via optional mounting device
Standard measuring plate 18 x 18 mm², Fe360

Operation & Display:-

Type of display LED
Number of LEDs 1 Piece(s)

Environmental Data:-

Ambient temperature, operation -25 … 70 °C
Ambient temperature, storage -25 … 70 °C

Data Sheet: Pdf

Model:-

IS 218MM/2NC-8E0 ; Part no.: 50129367
IS 218 MM/4NC-12E-S12 ; Part no.: 50129366
IS 218MM/4NC-20N ; Part no.: 50129365
IS 218MM/4NC-8E0 ; Part no.: 50129364
IS 218MM/2NC-8N0-S12 ; Part no.: 50129363
IS 218MM/2NC-8N0 ; Part no.: 50129362
IS 218MM/4NC-8N0-S12 ; Part no.: 50129361
IS 218MM/4NC-8N0 ; Part no.: 50129360
IS 218MM/4NC-5E0-S12 ; Part no.: 50127466
ISS 218MM/4NC-12E-S12 ; Part no.: 50120273
IS 218MM/4NC-5E0 ; Part no.: 50118521
IS 218MM/4NO-12E-S12 ; Part no.: 50114427
ISS 218MM/4NO-5E0 ; Part no.: 50112915
ISS 218MM/4NO-5E0-S12 ; Part no.: 50112293
IS 218MM/2NO-8E0 ; Part no.: 50112104
IS 218MM/2NO-12E ; Part no.: 50111954
IS 218MM/2NO-20N ; Part no.: 50111953
IS 218MM/4NC-8E0-S12 ; Part no.: 50109702
IS 218MM/4NO-8E0-S12 ; Part no.: 50109701
IS 218MM/4NO-8E0 ; Part no.: 50109700
IS 218MM/2NO-8N0-S12 ; Part no.: 50109699
IS 218MM/2NO-8N0 ; Part no.: 50109698
