Leuze Inductive Proximity Sensor IS 144 PP/4NO-20E-TB.4 , 50130014
Basic Data:-
| Series | 144 |
| Typ. operating range limit Sn | 20 mm |
| Operating range Sa | 0 … 16 mm |
Electrical Data:-
| Protective circuit | Overload protection Polarity reversal protection Short circuit protected |
Performance Data:-
| Supply voltage UB | 10 … 30 V, DC |
| Residual ripple | 10 %, From UB |
| Open-circuit current | 0 … 10 mA |
| Temperature drift, max. (in % of Sr) | 10 % |
| Repeatability, max. (in % of Sr) | 1 % |
| Switching hysteresis | 15 % |
Outputs:-
| Number of digital switching outputs | 1 Piece(s) |
Switching Outputs:-
| Voltage type | DC |
| Switching current, max. | 200 mA |
| Residual current, max. | 0.01 mA |
| Voltage drop | ≤ 2 V |
Switching Outputs 1:-
| Switching element | Transistor, PNP |
| Switching principle | NO (normally open) |
Time Behavior:-
| Switching frequency | 300 Hz |
Connection:-
| Number of connections | 1 Piece(s) |
Connection 1:-
| Function | Signal OUT Voltage supply |
| Type of connection | Terminal |
| No. of pins | 4 -pin |
Mechanical Data:-
| Design | Cubic |
| Dimension (W x H x L) | 115 mm x 40 mm x 140 mm |
| Type of installation | Embedded |
| Housing material | Plastic |
| Plastic housing | Polybutylene (PBT) |
| Sensing face material | Plastic, Polybutylene (PBT) |
| Housing color | Black Red, RAL 3000 |
| Type of fastening | Through-hole mounting |
| Standard measuring plate | 60 x 60 mm², Fe360 |
Operation & Display:-
| Type of display | LED |
| Number of LEDs | 2 Piece(s) |
Environmental Data:-
| Ambient temperature, operation | -25 … 70 °C |
| Ambient temperature, storage | -25 … 70 °C |
DIA 12MM:
ISS 112MM/4NC-6E0-M12 ; Part no.: 50136037
ISS 112MM/4NO-6E0-M12 ; Part no.: 50136036
ISS 112MM/2NC-6E0-M12 ; Part no.: 50136035
ISS 112MM/2NO-6E0-M12 ; Part no.: 50136034
ISS 112MM/4NC-4E0-M12 ; Part no.: 50136033
ISS 112MM/4NO-4E0-M12 ; Part no.: 50136032
ISS 112MM/2NC-4E0-M12 ; Part no.: 50136031
ISS 112MM/2NO-4E0-M12 ; Part no.: 50136030
ISS 112MM/4NC-6E0 ; Part no.: 50136029
ISS 112MM/4NO-6E0 ; Part no.: 50136028
ISS 112MM/2NC-6E0 ; Part no.: 50136027
ISS 112MM/2NO-6E0 ; Part no.: 50136026
ISS 112MM/4NC-4E0 ; Part no.: 50136025
ISS 112MM/4NO-4E0 ; Part no.: 50136024
ISS 112MM/2NC-4E0 ; Part no.: 50136023
ISS 112MM/2NO-4E0 ; Part no.: 50136022
ISS 112MM/4NC-8N0-M12 ; Part no.: 50136021
ISS 112MM/4NO-8N0-M12 ; Part no.: 50136020
ISS 112MM/2NC-8N0-M12 ; Part no.: 50136019
ISS 112MM/2NO-8N0-M12 ; Part no.: 50136018
ISS 112MM/4NC-8N0 ; Part no.: 50136017
ISS 112MM/4NO-8N0 ; Part no.: 50136016
ISS 112MM/2NC-8N0 ; Part no.: 50136015
ISS 112MM/2NO-8N0 ; Part no.: 50136014
IS 112MM/2NO-4E0-PUR ; Part no.: 50134444
IS 112MM/4NO-4E0-PUR ; Part no.: 50134443
IS 112 MM/4NC-8N0-M12; Part no.: 50129887
IS 112 MM/4NO-8N0-M12 ; Part no.: 50129886
IS 112 MM/2NC-8N0-M12 ; Part no.: 50129885
IS 112 MM/2NO-8N0-M12 ; Part no.: 50129884
IS 112 MM/4NC-6E0-M12 ; Part no.: 50129883
IS 112 MM/4NO-6E0-M12 ; Part no.: 50129882
IS 112 MM/2NC-6E0-M12 ; Part no.: 50129881
IS 112 MM/2NO-6E0-M12 ; Part no.: 50129880
IS 112 MM/4NC-4E0-M12 ; Part no.: 50129879
IS 112 MM/4NO-4E0-M12 ; Part no.: 50129878
IS 112 MM/2NC-4E0-M12 ; Part no.: 50129877
IS 112 MM/2NO-4E0-M12 ; Part no.: 50129876
IS 112 MM/4NC-8N0 ; Part no.: 50129875
IS 112 MM/4NO-8N0 ; Part no.: 50129874
IS 112 MM/2NC-8N0 ; Part no.: 50129873
IS 112 MM/2NO-8N0 ; Part no.: 50129872
IS 112 MM/4NC-6E0 ; Part no.: 50129871
IS 112 MM/4NO-6E0 ; Part no.: 50129870
IS 112 MM/2NC-6E0 ; Part no.: 50129869
IS 112 MM/2NO-6E0 ; Part no.: 50129868
IS 112 MM/4NC-4E0 ; Part no.: 50129867
IS 112 MM/4NO-4E0 ; Part no.: 50129866
IS 112 MM/2NC-4E0 ; Part no.: 50129865
IS 112 MM/2NO-4E0 ; Part no.: 50129864
ISS 212MM/2NO-4E0 ; Part no.: 50145947
ISS 212MM/44-8N0-S12 ; Part no.: 50141477
ISS 212MM/44-8N0 ; Part no.: 50141476
ISS 212MM/44-4E0-S12 ; Part no.: 50141475
ISS 212MM/44-4E0 ; Part no.: 50141474
ISS 212MM/44-4N0-S12 ; Part no.: 50141473
ISS 212MM/44-4N0 ; Part no.: 50141472
ISS 212MM/44-2E0-S12 ; Part no.: 50141471
ISS 212MM/44-2E0 ; Part no.: 50141470
ISS 212MM/4NC-6E0-S12 ; Part no.: 50133409
IS 212MM/2NC-2E0 ; Part no.: 50129415
ISS 212MM/4NC-4E0 ; Part no.: 50129359
IS 212MM/4NC-8N0-S12 ; Part no.: 50129358
IS 212MM/4NC-8N0 ; Part no.: 50129357
IS 212MM/2NC-8N0 ; Part no.: 50129356
IS 212MM/4NC-10N ; Part no.: 50129355
IS 212MM/2NO-4E0-S12 ; Part no.: 50129354
IS 212MM/4NC-4E0 ; Part no.: 50129353
IS 212MM/2NC-4N0 ; Part no.: 50129352
IS 212MM/4NC-4N0 ; Part no.: 50129351
IS 212MM/4NC-2E0 ; Part no.: 50129350
IS 212MM/2NC-4N0-S12 ; Part no.: 50121012
IS 212MM/2NO-8N0-S12 ; Part no.: 50120274
IS 212MM/2NC-4E0 ; Part no.: 50114380
IS 212MM/4NC-10N-S12 ; Part no.: 50114052
IS 212MM/4NC-4N0-S12 ; Part no.: 50112914
IS 212MM/4NO-8N0-S12 ; Part no.: 50112808
IS 212MM/4NO-8N0 ; Part no.: 50112807
IS 212MM/2NO-8N0 ; Part no.: 50112806
ISS 212MM/2NO-4N0 ; Part no.: 50112209
ISS 212MM/4NO-4N0-S12 ; Part no.: 50111963
IS 212MM/2NO-10N ; Part no.: 50111952
IS 212MM/4NC-2E0-S12 ; Part no.: 50111870
ISS 212MM/2NC-4E0-S12 ; Part no.: 50111741
IS 212MM/4NO-10N ; Part no.: 50109689
ISS 212MM/2NO-6E0-S12 ; Part no.: 50109688
ISS 212MM/2NO-4E0-S12 ; Part no.: 50109687
ISS 212MM/4NO-4E0-S12 ; Part no.: 50109685
ISS 212MM/4NO-4E0 ; Part no.: 50109684
IS 212MM/2NO-6E0 ; Part no.: 50109682
ISS 212MM/4NO-10N-S12 ; Part no.: 50109680
ISS 212MM/4NO-6E0-S12 ; Part no.: 50109679
IS 212MM/4NO-6E0 ; Part no.: 50109678
IS 212MM/2NC-4E0-S12 ; Part no.: 50109677
ISS 212MM/4NC-4E0-S12 ; Part no.: 50109676
IS 212MM/2NO-4E0 ; Part no.: 50109675
IS 212MM/4NC-4E0-S12 ; Part no.: 50109674
IS 212MM/4NO-4E0-S12 ; Part no.: 50109673
IS 212MM/4NO-4E0 ; Part no.: 50109672
IS 212MM/2NO-4N0-S12 ; Part no.: 50109671
IS 212MM/2NO-4N0 ; Part no.: 50109670
IS 212MM/4NO-4N0-S12 ; Part no.: 50109669
IS 212MM/4NO-4N0 ; Part no.: 50109668
IS 212MM/2NO-2E0 ; Part no.: 50109666
IS 212MM/4NO-2E0-S12 ; Part no.: 50109665
IS 212MM/4NO-2E0 ; Part no.: 50109664
IS 212FM/2NO.5-3E0 ; Part no.: 50128178
IS 212FM/2NO.5-3E0-S12 ; Part no.: 50128177
IS 212FM/4NO.5-3E0 ; Part no.: 50128176
IS 212FM/4NO.5-3E0-S12 ; Part no.: 50128175
IS 212FM/4NC.5-3E0-S12 ; Part no.: 50128173
IS 212FM/4NO.5F-10N-S12 ; Part no.: 50109738
IS 212FM/4NO.5F-6E0-S12 ; Part no.: 50109736
IS 212MM/1NO.3-2E0 ; Part no.: 50128150
IS 212MM/1NC.3-2E0 ; Part no.: 50128149
Data Sheet: Pdf
