ISS 244PP.1/44-20E-S12, 50133520 Leuze Inductive Proximity Sensor
Inductive Proximity Sensor
Specifications:-
Basic Data:-
| Series | 244 |
| Typ. operating range limit Sn | 20 mm |
| Operating range Sa | 0 … 16.2 mm |
Special Version:-
| Special version | Antiviolent |
Electrical Data:-
| Protective circuit | Inductive protection Polarity reversal protection Short circuit protected |
Performance Data:-
| Supply voltage UB | 10 … 30 V, DC |
| Residual ripple | 0 … 20 %, From UB |
| Open-circuit current | 0 … 30 mA |
| Temperature drift, max. (in % of Sr) | 10 %, Over the entire operating temperature range |
| Repeatability, max. (in % of Sr) | 10 %, For UB = 20 … 30 V DC, ambient temperature Ta = 23 °C ± 5 °C |
| Switching hysteresis | 15 % |
Outputs:-
| Number of digital switching outputs | 2 Piece(s) |
Switching Outputs:-
| Voltage type | DC |
| Switching current, max. | 200 mA |
| Residual current, max. | 0.01 mA |
| Voltage drop | ≤ 2 V |
Switching Outputs 1:-
| Switching element | Transistor, PNP |
| Switching principle | NO contact – Antivalent |
Switching Outputs 2:-
| Switching element | Transistor, PNP |
| Switching principle | NC contact – Antivalent |
Time Behavior:-
| Switching frequency | 100 Hz |
| Readiness delay | 100 ms |
Connection:-
| Number of connections | 1 Piece(s) |
Connection 1:-
| Function | Signal OUT Voltage supply |
| Type of connection | Connector |
| Thread size | M12 |
| Type | Male |
| Material | Metal |
| No. of pins | 4 -pin |
| Encoding | A-coded |
Mechanical Data:-
| Design | Cubic |
| Dimension (W x H x L) | 40 mm x 40 mm x 67 mm |
| Type of installation | Embedded |
| Housing material | Plastic |
| Plastic housing | PA 66 |
| Sensing face material | Plastic, Polyamide (PA 66) |
| Net weight | 120 g |
| Housing color | Black Red, RAL 3000 |
| Type of fastening | Through-hole mounting |
| Standard measuring plate | 60 x 60 mm², Fe360 |
Operation & Display:-
| Type of display | LED |
| Number of LEDs | 4 Piece(s) |
Environmental Data:-
| Ambient temperature, operation | -25 … 85 °C |
| Ambient temperature, storage | -25 … 85 °C |
Data Sheet: Pdf
