IS 212MM/1NO.3-2E0,50128150 Leuze Inductive Proximity Sensor
Specifications:-
Basic Data:-
| Series | 212 |
| Typ. operating range limit Sn | 2 mm |
| Operating range Sa | 0 … 1.6 mm |
Measurement Data:
| Repeatability | 0.5 mm |
Electrical Data:-
| Protective circuit | Inductive protection Polarity reversal protection Short circuit protected |
Performance Data:-
| Supply voltage UB | 10 … 320 V, AC/DC |
| Residual ripple | 0 … 20 %, From UB |
| Open-circuit current | 0 … 1 mA |
| Temperature drift, max. (in % of Sr) | 10 %, Over the entire operating temperature range |
| Repeatability, max. (in % of Sr) | 5 %, For UB = 20 … 30 V DC, ambient temperature Ta = 23 °C ± 5 °C |
| Switching hysteresis | 20 % |
Outputs:-
| Number of digital switching outputs | 1 Piece(s) |
Switching Outputs:-
| Voltage type | AC/DC |
| Switching current, max. | 200 mA |
| Voltage drop | ≤ 2 V |
Switching Outputs 1:-
| Switching element | Relay, NO |
| Switching principle | NO (normally open) |
Time Behavior:-
| Switching frequency | 3,000 Hz |
| Oscillator frequency | 350,000 Hz |
| Readiness delay | 10 ms |
Connection:-
| Number of connections | 1 Piece(s) |
Connection 1:-
| Function | Voltage supply |
| Type of connection | Cable |
| Cable length | 2,000 mm |
| Sheathing material | PVC |
| Cable color | Black |
| Number of conductors | 2 -wire |
| Wire cross section | 0.34 mm² |
Mechanical Data:-
| Design | Cylindrical |
| Thread size | M12 x 1 mm |
| Dimension (Ø x L) | 12 mm x 52 mm |
| Type of installation | Embedded |
| Housing material | Metal |
| Metal housing | Chromed brass |
| Sensing face material | Plastic, Polybutylene (PBT) |
| Net weight | 93 g |
| Housing color | Red, RAL 3000 Silver |
| Type of fastening | Mounting thread Via optional mounting device |
| Standard measuring plate | 12 x 12 mm², Fe360 |
Operation & Display:-
| Type of display | LED |
| Number of LEDs | 1 Piece(s) |
Environmental Data:-
| Ambient temperature, operation | -25 … 70 °C |
