HT36/2,50147089 Leuze Diffuse Sensor

In Stock
Highlights:
  • RANGE: 150-2500MM
  • OUTPUT: NPN-LIGHT SWITCHING
  • SUPPLY VOLTAGE: 10-30VDC
  • CABLE TYPE
  • 3 WIRE
  • PLASTIC HOUSING
Compare
Estimated Delivery: 1-3 Days
15 June - 17 June
Description

HT36/2,50147089 Leuze Diffuse Sensor

Diffuse sensor with background suppression

Specifications:-

Basic Data:-

Series 36
Operating principle Diffuse reflection principle with background suppression

Optical Data:-

Black-white error < 10% up to 800 mm
Operating range Guaranteed operating range
Operating range, white 90% 0.01 … 2.5 m
Operating range, gray 18% 0.05 … 1.5 m
Operating range, black 6% 0.08 … 1.1 m
Operating range limit Typical operating range
Operating range limit 0.01 … 2.5 m
Adjustment range 150 … 2,500 mm
Beam path Focused
Light source LED, Red
Wavelength 645 nm
LED group Exempt group (in acc. with EN 62471)
Type of light spot geometry Rectangular
Focus Fixed

Electrical Data:-

Protective circuit Polarity reversal protection
Short circuit protected
Transient protection

Performance Data:-

Supply voltage UB 10 … 30 V, DC, Incl. residual ripple
Residual ripple 0 … 15 %, From UB
Open-circuit current 0 … 30 mA

Outputs:-

Number of digital switching outputs 1 Piece(s)

Switching Outputs 1:-

Switching element Transistor, NPN
Switching principle Light switching

Time Behavior:-

Switching frequency 250 Hz
Response time 2 ms
Readiness delay 300 ms

Connection:-

Connection 1:-

Function Signal OUT
Voltage supply
Type of connection Cable
Cable length 2,000 mm
Sheathing material PUR
Cable color Black
Number of conductors 3 -wire
Wire cross section 0.14 mm²

Mechanical Data:-

Dimension (W x H x L) 20.5 mm x 76.3 mm x 44 mm
Housing material Plastic
Plastic housing PC-PBT
Lens cover material Plastic / PMMA
Net weight 100 g
Housing color Black
Type of fastening Through-hole mounting
Via optional mounting device



Operation & Display:-

Type of display LED
Operational controls Multiturn potentiometer
Function of the operational control Range adjustment

Environmental Data:-

Ambient temperature, operation -40 … 60 °C
Ambient temperature, storage -40 … 70 °C

Data Sheet: Pdf

DIFFUSE PHOTOELECTRIC SENSOR:-
HT25CI.HFXF/4P Part no.: 50150809,SETHT25CI-450F.HF/4P410M12 Part no.: 50150730, HT25CI-450F.HF/4P-410-M12 Part no.: 50150729,
SETHT25CI-300F.HF/4P410M12 Part no.: 50150728, HT25CI-300F.HF/4P-410-M12 Part no.: 50150727, SETHT25CI-300F.HF/PX200M12 Part no.: 50150373,
HT25CI-300F.HF/PX-200-M12 Part no.: 50150372 HT3CI.HF/4X-M8 Part no.: 50149631, HT3C.BVXL/4P-M8 Part no.: 50149612, ODT25B/L6.32-2500,200-S12 Part no.: 50149096
