IS 105MM/4NO-0E8-PUR, 50134445 Leuze Inductive Proximity Sensor

In Stock
Highlights:
  • DIA: 05MM
  • SN: 0.8MM
  • PNP-NO
  • SUPPLY VOLTAGE: 10-30VDC
  • CABLE TYPE
  • 3 WIRE
  • METAL HOUSING
  • EMBEDDED



Compare
Estimated Delivery: 1-3 Days
21 June - 23 June
Description

IS 105MM/4NO-0E8-PUR, 50134445 Leuze Inductive Proximity Sensor

Inductive Proximity Sensor

Specifications:-

Basic Data:-

Series 105
Typ. operating range limit Sn 0.8 mm

Electrical Data:-

Protective circuit Overload protection
Polarity reversal protection
Short circuit protected

Performance Data:-

Supply voltage UB 10 … 30 V, DC
Open-circuit current 0 … 10 mA
Temperature drift, max. (in % of Sr) 10 %
Repeatability, max. (in % of Sr) 1 %

Outputs:-

Number of digital switching outputs 1 Piece(s)

Switching Outputs:-

Voltage type DC
Switching current, max. 100 mA
Residual current, max. 0.01 mA
Voltage drop ≤ 2 V

Switching Outputs 1:-

Switching element Transistor, PNP
Switching principle NO (normally open)

Time Behavior:-

Switching frequency 2,000 Hz

Connection:-

Number of connections 1 Piece(s)

Connection 1:-

Function Signal OUT
Voltage supply
Type of connection Cable
Cable length 2,000 mm
Sheathing material PUR
Cable color Black
Number of conductors 3 -wire
Wire cross section 0.15 mm²

Mechanical Data:-

Design Cylindrical
Thread size M5 x 0.5 mm
Dimension (Ø x L) 5 mm x 28 mm
Type of installation Embedded
Housing material Stainless steel
Sensing face material Plastic, Polyoxymethylene (POM)
Housing color Red, RAL 3000
Silver
Type of fastening Mounting thread
Standard measuring plate 5 x 5 mm², Fe360

Operation & Display:-

Type of display LED
Number of LEDs 1 Piece(s)

Environmental Data:-

Ambient temperature, operation -25 … 70 °C
Ambient temperature, storage -25 … 70 °C

Data Sheet: Pdf

IS 105MM/4NO-0E8-PUR ; Part no.: 50134445
IS 205MM/4NC-1E5 ; Part no.: 50134895
IS 205MM/4NO-1E5 ; Part no.: 50113213
IS 205MM/4NO-1E5-S8.3; Part no.: 50113212
