Home » Shop » ET5.3/2N, 50122582 Leuze Energetic Diffuse Sensor

ET5.3/2N, 50122582 Leuze Energetic Diffuse Sensor

In Stock
Highlights:
  • RANGE: 0-1m
  • OUTPUT: NPN-LIGHT SWITCHING /DARK SWITCHING
  • SUPPLY VOLTAGE: 10-30VDC
  • CABLE TYPE
  • 4 WIRE
  • PLASTIC HOUSING



Compare
Estimated Delivery: 1-3 Days
15 June - 17 June
Description

ET5.3/2N, 50122582 Leuze Energetic Diffuse Sensor

Diffuse Sensor

Specifications:-

Basic Data:-

Series 5
Operating principle Diffuse reflection principle

Optical Data:-

Operating range Guaranteed operating range
Operating range, white 90% 0.001 … 0.7 m
Operating range, gray 50% 0.001 … 0.59 m
Operating range, gray 18% 0.003 … 0.39 m
Operating range, black 6% 0.005 … 0.28 m
Operating range limit Typical operating range
Operating range limit, white 90% 0 … 1 m
Operating range limit, gray 50% 0.001 … 0.85 m
Operating range limit, gray 18% 0.003 … 0.55 m
Operating range limit, black 6% 0.002 … 0.4 m
Light source LED, Red
Wavelength 620 nm
LED group Exempt group (in acc. with EN 62471)

Electrical Data:-

Protective circuit Polarity reversal protection
Short circuit protected

Performance Data:-

Supply voltage UB 10 … 30 V, DC, Incl. residual ripple
Residual ripple 0 … 15 %, From UB
Open-circuit current 0 … 20 mA

Outputs:-

Number of digital switching outputs 2 Piece(s)

Switching Outputs:-

Switching element Transistor, NPN
Switching principle Light switching

Switching Outputs 1:-

Switching element Transistor, NPN
Switching principle Dark switching

Time Behavior:-

Switching frequency 500 Hz
Response time 1 ms
Readiness delay 300 ms

Connection:-

Connection 1:-

Function Signal OUT
Voltage supply
Type of connection Cable
Cable length 2,000 mm
Sheathing material PUR
Cable color Black
Number of conductors 4 -wire
Wire cross section 0.2 mm²

Mechanical Data:-

Dimension (W x H x L) 14 mm x 32.5 mm x 20.2 mm
Housing material Plastic
Plastic housing ABS
Lens cover material Plastic
Net weight 70 g
Housing color Black
Red

Operation & Display:-

Type of display LED
Operational controls Teach button

Environmental Data:-

Ambient temperature, operation -40 … 60 °C
Ambient temperature, storage -40 … 70 °C

Data Sheet: Pdf

DIFFUSE PHOTOELECTRIC SENSOR:

HT25CI.HFXF/4P Part no.: 50150809,SETHT25CI-450F.HF/4P410M12 Part no.: 50150730, HT25CI-450F.HF/4P-410-M12 Part no.: 50150729,
SETHT25CI-300F.HF/4P410M12 Part no.: 50150728, HT25CI-300F.HF/4P-410-M12 Part no.: 50150727, SETHT25CI-300F.HF/PX200M12 Part no.: 50150373,
HT25CI-300F.HF/PX-200-M12 Part no.: 50150372 HT3CI.HF/4X-M8 Part no.: 50149631, HT3C.BVXL/4P-M8 Part no.: 50149612, ODT25B/L6.32-2500,200-S12 Part no.: 50149096.
